Product Details:
Payment & Shipping Terms:
|
| Certificate: | CCC / CE / VDE / CEA / | Connector: | Original / Equivalent |
|---|---|---|---|
| Wire: | Types / Color / Awg Optional | Sample: | Free Sample |
| High Light: | male to male cable,wire harness connectors |
||
|
ELECTRICAL DATA
|
|
|
Impedance
|
50Ω
|
|
Frequency range
|
DC-6Ghz
|
|
VSWR
|
1.3 max
|
|
Voltage
|
60V AC(rms)
|
|
Insulation Resisitance
|
500 MΩ min.
|
|
Insertion Loss
|
0.3dB max. at 1.0 GHZ/0.5DB max. at 2.0 GHZ
|
|
MATERIAL DATA
|
|
|
Bodies
|
Brass--gold/Nickel plating
|
|
Pin contacts
|
Brass--gold plating
|
|
Socket contacts
|
Copper-beryllium alloy--Au plating
|
|
Insulator
|
PTFE
|
|
Cable type
|
UL
|
|
Application
|
smartphone,tablet PC,wifi antenna,GPS antenna, RF device etc
|
|
Temperature range
|
-40°C to +80°C
|
Contact Person: Mr. Liu
Tel: 15099965979
