EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles

EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles
EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles

Large Image :  EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles

Product Details:
Place of Origin: China
Brand Name: Ritian
Certification: CE
Model Number: RT-HVIL-02P-S1-C16
Payment & Shipping Terms:
Minimum Order Quantity: 100 PCS
Price: Negotiable
Packaging Details: Neutral Carton or Customized
Delivery Time: 5-8 days for the samples, 15-25 days for bulk
Payment Terms: T/T
Supply Ability: 30000 PCS / Month
Contact Now
Detailed Product Description
Color: Orange (HV Standard) Orientation: Straight (180°)
Gender: Available As Male Plug, Female Socket, Or Pair Interface: Snap-lock + Crimp Terminals
Keying: Error-proof Multi-key Positions (common In Series) Connection Method: Crimp/Snap Buckle
Shielding: Electromagnetic Shielding Support Application Fields: Battery Packs, Motor Controllers, OBC, DCDC, PTC Heaters

EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles


Product Definition



This is a compact, waterproof 2-pin (two-core) high-voltage connector designed for small-current applications in new energy vehicles (NEVs/EVs), energy storage systems, and related high-voltage electrical connections. It features a straight (inline/direct insertion) plug design with snap/crimp interface, orange housing (standard for HV safety), and robust sealing for reliable performance in demanding automotive environments. It supports male and female pairing for secure power transmission between components like battery packs, chargers, inverters, air conditioning systems, and PDUs.


EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles 0



Technical Parameters: waterproof 2-pin high voltage connector



Parameter Specification
Number of Pins/Cores 2-Pin (Two-Core)
Type Straight Plug, Male/Female Pair
Rated Voltage High Voltage (typically 800V-1500V DC)
Rated Current Small Current (e.g., 16A-40A)
Interface Snap/Crimp (Tool-free welding-free)
Color Orange
Protection Rating Waterproof (IP67 or higher/IP6K9K)
Operating Temp. -40°C to +130°C (typical)
Applications EV/NEV, Energy Storage, Rail Transit
Housing Material High-performance engineering plastic
Features HVIL (High Voltage Interlock) capable, Shielding support


Key Features


  1. High Safety & Reliability: High-voltage rated with excellent insulation and touch-proof design; orange color indicates HV warning.
  2. Waterproof & Durable: IP67/IP6K9K-level protection (typical for this category), resistant to dust, water, and harsh road conditions.
  3. Easy Installation: Tool-free snap/crimp connection, straight plug for quick assembly.
  4. Compact & Versatile: Small current design (typically 16-40A range), suitable for space-constrained applications.
  5. Wide Compatibility: Ideal for new energy electric vehicles, energy storage connectors, rail transit, and other high-voltage systems.
  6. Cost-Effective: Bulk pricing around ¥20, high inventory, fast shipping.
  7. Secondary Locking: Enhanced mating security (common in similar EVH2/LHV2 series).

EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles 1

EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles 2

EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles 3



Application Scenarios


  • New Energy Electric Vehicles (battery packs, motor controllers, OBC, DCDC, PTC heaters, air conditioning compressors).
  • Energy Storage Systems (BESS) high-voltage connections.
  • Rail transit and other electric mobility high-voltage wiring.
  • PDU (Power Distribution Units) and high-voltage distribution boxes.
  • Harsh environment wiring requiring waterproof and vibration-resistant connections.

EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles 4

EV High Voltage Interlock Connector 2 Pin Straight Type for Energy Storage & Electric Vehicles 5





#Tags / Keywords

high voltage connector, 2 pin HV connector, EVH2 style connector, NEV waterproof socket, electric vehicle high voltage interlock
