| Model: | D Sub AISG RET Cable | Feature: | Waterproof |
|---|---|---|---|
| Gender: | Male To Female | Pin: | 8 Pin 9 Pin , 8 Pin To DB9 |
| Protection Class: | IP67 IP68 | Application: | AISG Remote Electrical Tilt Control Cable |
| Wire Core Material: | Silver Plated Copper Wire | Application: | Computer, Electronic, Automobile, RF, Home Appliance |
| High Light: | DB9 Female Connector AISG RET Cable,Rru To Rcu AISG RET Cable,8 Pin AISG Control Cable |
||
Rru to Rcu Ret AISG Control Cable RET Cable Male to AISG jumper control DB9 Female connector
The Antenna Interface Standards Group (AISG) creates and maintains standards for the control and monitoring interface between a base station and a variety of tower-top equipment. These include antennas with remote electrical tilt (RET), tower mounted amplifiers and a variety of sensors that are used to monitor the operation of tower-top equipment. These are referred to as subunits. A complete list of those currently supported can be found here.
RET cable- DB9 Male to AISG Female- 5m- IP67
Feeds data and power to RET system components
RET/AISG 6-Conductor Control Cable Assembly 10M
The AISG Series control cables are used to feed data and power from the controller to the RET remote electrical tilt system
Type: AISG
Cable: RET Control Cable
Protocol: AISG 1.1 , AISG 2.0
AISG: 8 PIN DIN Female
D-SUB: 9 PIN D-SUB Male
Length Available:1-100 meters
Color: Black
1.RET control cable with DB9 and AISG connectors
2.Feeds data and power to RET system components
3.Directly connects RET
