| Name: | M8 Front Mout Connector | Application: | Automotive /industry/ LED Etc |
|---|---|---|---|
| Rated Voltage: | OCP250V For 3/4 Pin, 60v For 5/6 Pin, 30V For 8/12/17 Pin | Body Material: | Brass, Nickel Plated |
| Contact: | DIP Contact | Type: | Circular Connector |
| Gender: | Male Female | Rated Current: | 4A For 3/4/5/6 Pin, 2A For 8pin, 1.5A For 12/17pin |
| Material Of Contact: | Phosphor Bronze , Gold Plated | Usage: | Miniature Sensors / Industrial Camera / Electrical Bike |
| High Light: | m5 waterproof connector,waterproof electric cable connectors |
||
M8 Circular 2 3 4 5 Pin Cable Sensor Plug IP67 Straight Cable Plug Panel Front Mount Socket Connector
| General Characteristics | ||
| Number of contact | 3 | 4 |
| Locking system | screw M5*0.5 | |
| Termination | solder, moulded on cable | |
| Wire guage in mm² | max 0.14 | |
| Wire guage in AWG | max 26 | |
| Shell protection | IP67/IP68 | |
| Mechanical operation | >500 mating cycles | |
| Upper temperature | +85℃ | |
| Lower temperature | -25℃ | |
| Electrical Characteristics | ||
| Rated voltage | 60V | |
| Pollution degree | III | |
| Test voltage | 500V±15V | |
| Rated current(40℃) | 1A | |
| Contact resistance | ≤10mΩ | |
| insulation resistance | ≥100MΩ | |
| Materials | ||
| Pin contact | CuZn | |
| Socket contact | CuSn | |
| Contact plating | Au | |
| Upper temperature | PA66(UL 94V-0) | |
| Female insent | PA66(UL 94V-0) | |
| Material of cable jacket | PVC or PUR | |
| Screw | CuZn | |
| Nut | CuZn | |
