| Material: | METAL | Gender: | Male To Female |
|---|---|---|---|
| Pin: | Multipole Pins | Application: | Automotive |
| Size: | M12 | IP Rating: | IP66,IP68 |
| High Light: | IP68 Male Female Cable Connector,M12 Male Female Cable Connector,Solderless M12 Circular Connector |
||
IP67 IP68 waterproof M12 Circular plug type solderless Male Female Cable connector
Available Description:
Shielded is available
Hexagon screw is available
Stainless steel screw is available
Anti-vibration locking screw design
IP67/IP68, RoHS, REACH, UL certificate
Generally Description:
Connector Series: M12
Standard: IEC 61076-2-101
Coding: A
Pins: 3
Gender: Male
Connector Design: Cable plug
Connector Locking System: Fix screw
Waterproof Rating: IP67/IP68
Ambient Temperature: -25℃~+85℃
Material:
Connector Body: PA66+GF
Contacts: Brass with gold plated
Screw/Nut: Brass with nickel plated
Waterproof 0-ring: FKM
Electrical data:
Rated Current: 4A
Rated Voltage: 250V
Contact Resistance: ≤5mΩ
Insulation Resistance: ≥100MΩ
